2020 Lonestar defender with low hrs has developed a vibration and rattle between 3100-3400 rpms. Any slower or faster the rattle isnt present. I'm starting to believe it's a drive train balance issue after some research. It seems others may have experienced this and taken to dealership for warranty but the rattle cant be duplicated or they cant fix the noise. It must be an issue as there are aftermarket vendors ( Sandcraft RCR and Super ATV) that offer drive line upgrades to fix the problem. They include both front and rear driveshafts that are balanced and phased properly with stronger u joints as well as a upgraded serviceable carrier bearing. Anyone else worked through this problem? TIA
Front end vibration and rattle
- Thread starter Phillip
- Start date
A hunt 2 remember
New member
- Joined
- Nov 22, 2019
- Messages
- 639
- Reaction score
- 113
Well, not necessarily that issue... but seems maybe you are feeling the clutches making their move in the mid range and you are getting a harmonic balance sounding off. As for the balanced HD drive line's and axles.... Not so much to fix a problem, other than WEAK LINQS... LOL... At say 1500 miles I blew a stock right front cv and replaced it with a set of Gorilla HD axles that have double plungers rather than just an inner plunger... now... the rest look VULNERABLE TO BREAKING!!! Hence HD replacements... as well as turbo rigs spinnin' one into a bannana....
GOOD LUCK!!!
GOOD LUCK!!!
Thanks but its definitely not coming from clutch area. With my son driving I can clearly hear it coming from front drivers side. When parked i have bumped all suspension parts and everything seems fine. I do get a rattle from the fan shroud and it seems the vibrations causing it to rattle. When looking at the aftermarket "fixes" they all stated it fixed a major issue with can am driveline vibrations. They have them for Polaris too... I'm not saying that's the answer but in my searches that's what I had seen. And if I do it at least its fixing a weak link right haha! Just didnt know if anyone had experienced it.
Check this link out and see what you think.
https://www.sandcraftmotorsports.com/wp-content/uploads/2020/04/Can-Am-Driveline-2.jpg
https://www.sandcraftmotorsports.com/wp-content/uploads/2020/04/Can-Am-Driveline-2.jpg
Andystoy19
Active member
- Joined
- Apr 24, 2019
- Messages
- 714
- Reaction score
- 159
My guess is you may have a loose CV jt. on your front right axle, do you have this vibration when in 2 wheel drive only, 4 wheel drive only or in all cases? I would not be a fan of installing a steady bearing on either drive shaft. Did you stay with stock tires or have you upgraded to larger or heavier tires?
Andystoy19
Active member
- Joined
- Apr 24, 2019
- Messages
- 714
- Reaction score
- 159
In your link the picture shows a picture of a bearing on a shaft (steady bearing) these were used years ago and are still used today on drive shafts that are long and have high torque. For example not used on pickups but used on trucks that are larger and have a large change in drive shaft angle. The short drive shafts on the defender shouldn't require a steady bearing and should be close to balanced and correctly phased from the factory. IMO
I need to correct my previous statement where I said my guess it was a loose cv joint on the right side, it should say left side if it is on the drivers side.
If you can raise the vehicle and block it safely with all four wheels off the ground you could put the vehicle in 2 wheel drive first to see if you can still hear the noise if not put it in four wheel drive and do the same. You can turn the steering from full left to right and back to see if the noise changes, this may help you determine exactly where the noise is coming from and you may see movement on the driveline (vibration) from the defective component.
The stock tires and suspension should not be a contributing factor to the noise and vibration, I changed my tires to the 30" Cryptid tires and they have a noticeable vibration at low speeds on pavement.
I need to correct my previous statement where I said my guess it was a loose cv joint on the right side, it should say left side if it is on the drivers side.
If you can raise the vehicle and block it safely with all four wheels off the ground you could put the vehicle in 2 wheel drive first to see if you can still hear the noise if not put it in four wheel drive and do the same. You can turn the steering from full left to right and back to see if the noise changes, this may help you determine exactly where the noise is coming from and you may see movement on the driveline (vibration) from the defective component.
The stock tires and suspension should not be a contributing factor to the noise and vibration, I changed my tires to the 30" Cryptid tires and they have a noticeable vibration at low speeds on pavement.
Strikedog73
New member
- Joined
- Oct 2, 2020
- Messages
- 1
- Reaction score
- 0
Any updates on this noise on the front end? I purchased 2020 max defender HD10 to hunt with and to no end could not find the source of the noise. It happens right around 32-3600rpm just like the OP. Dealer looked and looked and could not find the issue. I decided to sell after a month of owning and bought a 2020 HD10 pro instead of the max. So I test drove and it had zero noise or vibration. Well low and behold 90 miles and it’s back, same noise at same rpm. This tells me that it’s not a unique noise to just mine. Any thoughts or info on the source?
Mark in Colorado
New member
- Joined
- Oct 21, 2019
- Messages
- 135
- Reaction score
- 48
Same here. Sounds like it’s coming from the front/right/passenger side when I turn LEFT. Just an annoying rattle. I’ve jacked it up and rubber-hammered everything. CV, maybe? -Mark
A hunt 2 remember
New member
- Joined
- Nov 22, 2019
- Messages
- 639
- Reaction score
- 113
Not sure if it's related... but the right front CV was my first to go.... Gorilla axles now...
A hunt 2 remember
New member
- Joined
- Nov 22, 2019
- Messages
- 639
- Reaction score
- 113
A hunt 2 remember
New member
- Joined
- Nov 22, 2019
- Messages
- 639
- Reaction score
- 113
A hunt 2 remember
New member
- Joined
- Nov 22, 2019
- Messages
- 639
- Reaction score
- 113
My rattle is gone.... figured it had to do with my right front outer CV joint.... Since it grenaded and I replaced it with lifetime guaranteed Gorilla axles...... my GROWL IS GONE!!
2021 can am defender limited hd 10 brand new with 150 miles. driveline vibration at all speeds and in both 2 and 4 wheel drive. I am to the point of removing the floor pans to inspect the driveline, but then it occurred to me.....I just dropped 30grand on this pos!!!!! Why should I inspect or try and figure out what the hell is going on with the vibration!!!!! answer-because I have limited faith that the dealer will do anything and is a 90 minute drive. This is a known problem, can anyone help with this one????? I know im not the first to ask for the warranty solution, cmon can am comrads, give a buddy some help before I rip this thing apart.....
I hear ya...mine has been back to the dealer...was told it was fixed..BS! I bought new so I wouldn't have to wrench for.....awhile. I'm thinking unbalanced driveshaft or axle...
